LTM4611IV Integrated Circuit Chip 15A µModule Buck Regulators LGA-133 Buck Converter

LTM4611IV Integrated Circuit Chip 15A µModule Buck Regulators LGA-133 Buck Converter​

Product Description Of LTM4611IV

LTM4611IV is a high density 15A output, switch mode DC/DC buck converter power supply capable of operating from very low voltage input supplies. Included in the package are the buck switching controller, power FETs, inductor and loop-compensation components.
The LTM4611IV delivers up to 15A continuous current at high efficiency from an input voltage of 1.5VIN up to 5.5VIN. The output voltage is set between 0.8V and 5V by a resistor. Only a few input and output capacitors are needed.

Specification Of LTM4611IV

Features Of LTM4611IV

Complete Switch Mode Power Supply
Input Voltage Range: 1.5V to 5.5V
15A DC Output
Output Voltage Range: 0.8V to 5V
±1.5% Total DC Output Error
Differential Remote Sensing for Precision Regulation
Current Mode Control/ Fast Transient Response
Overcurrent Foldback Protection
Parallel Multiple LTM4611s for Current Sharing
Frequency Synchronization
Selectable Pulse-Skipping or Burst Mode® Operation
Soft-Start/Voltage Tracking
Up to 94% Efficiency
Output Overvoltage Protection
Small 15mm × 15mm × 4.32mm LGA Package

Applications Of LTM4611IV

Telecom Servers and Networking Equipment
Storage and ATCA Cards
General Purpose Point of Load Regulation
